Gallery

NDT Field Work Images

This gallery shows real on-site field work completed by our technicians. It highlights safe, controlled prep and inspection support in industrial spaces. Every job is documented to help meet quality and compliance requirements.

Technician grinding a metal surface to prepare for NDT visual inspection.

Surface prep before inspection.

Technician performing close visual inspection on overhead ducting seam using hand tool and light.

Inspection check on overhead joint.

Technician inspecting an overhead HVAC or duct surface while positioned safely on an A-frame ladder.

Overhead inspection from ladder access.

Wide interior view of a clean industrial facility featuring multiple large white sloped components along a blue floor, showcasing a professional workspace maintained for NDT field services.

Maintaining structural integrity across large-scale industrial operations.

Mechanical room with large HVAC units and ducting laid out for inspection, labeling, and access checks.

Mechanical room walkthrough inspection.

Heat Exchanger Inspection Images

This section shows inspection work inside heat exchangers and tube sheets. We verify internal condition, tube integrity, and overall readiness for service. Each inspection is documented for maintenance planning and quality control.

Technician inspecting the inside of a heat exchanger tube sheet for condition and integrity checks.

Internal tube sheet inspection in progress.

Technician using an inspection probe to check heat exchanger tube sheet openings for damage or wear.

Tube sheet scan for defects.

Piping & Fabrication Inspection Images

This section shows fabrication and piping components staged for inspection. We document fit-up, weld areas, and component condition before field install. It supports quality control, traceability, and code-compliant reporting.

Fabricated pipe spool with flanged end staged in shop for NDT inspection and documentation.

Pipe spool staged for inspection.

Close-up of tube sheet face on heat exchanger component prepared for inspection and documentation.

Tube bundle face, condition check.
